Chapter 1 Configuring Fallback Bridging
Configuring Fallback Bridging
To return to the default setting, use the no bridge-group bridge-group priority interface configuration
command.
This example shows how to change the priority to 20 on a port in bridge group 10:
Switch(config)# interface gigabitethernet2/0/1
Switch(config-if)# bridge-group 10 priority 20
Assigning a Path Cost
Each port has a path cost associated with it. By convention, the path cost is 1000/data rate of the attached
LAN, in Mb/s.
Beginning in privileged EXEC mode, follow these steps to assign a path cost. This procedure is optional.
To return to the default path cost, use the no bridge-group bridge-group path-cost interface
configuration command.
This example shows how to change the path cost to 20 on a port in bridge group 10:
Switch(config)# interface gigabitethernet2/0/1
Switch(config-if)# bridge-group 10 path-cost 20
Adjusting BPDU Intervals
• Adjusting the Interval between Hello BPDUs, page 1-8 (optional)
• Changing the Forward-Delay Interval, page 1-8 (optional)
• Changing the Maximum-Idle Interval, page 1-9 (optional)
Step 5
show running-config Verify your entry.
Step 6
copy running-config startup-config (Optional) Save your entry in the configuration file.
Command Purpose
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the port to set the path cost, and enter interface configuration
mode.
Step 3
bridge-group bridge-group path-cost
cost
Assign the path cost of a port.
• For bridge-group, specify the bridge group number. The range is 1
to 255.
• For cost, enter a number from 0 to 65535. The higher the value, the
higher the cost.
– For 10 Mb/s, the default path cost is 100.
– For 100 Mb/s, the default path cost is 19.
– For 1000 Mb/s, the default path cost is 4.
Step 4
end Return to privileged EXEC mode.
Step 5
show running-config Verify your entry.
Step 6
copy running-config startup-config (Optional) Save your entry in the configuration file.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
