Cisco Catalyst 3560-X User Manual

1-20
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring DHCP Features and IP Source Guard
Configuring IP Source Guard
To disable IP source guard with source IP address filtering, use the no ip verify source interface
configuration command.
To delete a static IP source binding entry, use the no ip source global configuration command.
This example shows how to enable IP source guard with source IP and MAC filtering on VLANs 10
and 11:
Switch# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# interface gigabitethernet0/1
Switch(config-if)# ip verify source port-security
Switch(config-if)# exit
Switch(config)# ip source binding 0100.0022.0010 vlan 10 10.0.0.2 interface
gigabitethernet0/1
Switch(config)# ip source binding 0100.0230.0002 vlan 11 10.0.0.4 interface
gigabitethernet0/1
Switch(config)# end
Configuring IP Source Guard for Static Hosts
• Configuring IP Source Guard for Static Hosts on a Layer 2 Access Port, page 1-21
• Configuring IP Source Guard for Static Hosts on a Private VLAN Host Port, page 1-24
or ip verify source port-security Enable IP source guard with source IP and MAC address filtering.
When you enable both IP source guard and port security by using the ip
verify source port-security interface configuration command, there are
two caveats:
• The DHCP server must support option 82, or the client is not
assigned an IP address.
• The MAC address in the DHCP packet is not learned as a secure
address. The MAC address of the DHCP client is learned as a secure
address only when the switch receives non-DHCP data traffic.
Step 4
exit Return to global configuration mode.
Step 5
ip source binding mac-address vlan
vlan-id ip-address inteface interface-id
Add a static IP source binding.
Enter this command for each static binding.
Step 6
end Return to privileged EXEC mode.
Step 7
show ip verify source [interface
interface-id]
Verify the IP source guard configuration.
Step 8
show ip source binding [ip-address]
[mac-address] [dhcp-snooping | static]
[inteface interface-id] [vlan vlan-id]
Display the IP source bindings on the switch, on a specific VLAN, or on
a specific interface.
Step 9
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
