Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring Resilient Ethernet Protocol
Monitoring REP
Configuring SNMP Traps for REP
You can configure the switch to send REP-specific traps to notify the SNMP server of link operational
status changes and port role changes. To configure REP traps, follow these steps, beginning in privileged
EXEC mode:
To remove the trap, enter the no snmp mib rep trap-rate global configuration command.
This example configures the switch to send REP traps at a rate of 10 per second:
Switch(config)# snmp mib rep trap-rate 10
Monitoring REP
Command Purpose
Step 1
rep preempt segment segment-id Manually triggers VLAN load balancing on the segment.
You will need to confirm the command before it is executed.
Step 2
show rep topology Displays REP topology information.
Command Purpose
Step 1
configure terminal Enters global configuration mode.
Step 2
snmp mib rep trap-rate value Enables the switch to send REP traps, and set the number of
traps sent per second. The range is from 0 to 1000. The default
is 0 (no limit imposed; a trap is sent at every occurrence).
Step 3
end Returns to privileged EXEC mode.
Step 4
show running-config Displays the REP trap configuration.
Step 5
copy running-config startup config (Optional) Saves your entries in the switch startup
configuration file.
Table 1-1 REP Monitoring Commands
Command Purpose
show interface [interface-id] rep [detail] Displays REP configuration and status for an interface or for all interfaces.
• (Optional) detail—displays interface-specific REP information.
show rep topology [segment segment_id]
[archive] [detail]
Displays REP topology information for a segment or for all segments,
including the primary and secondary edge ports in the segment.
• (Optional) archive—displays the last stable topology.
Note An archive topology is not retained when the switch reloads.
• (Optional) detail—displays detailed archived information.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
