Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring LLDP, LLDP-MED, and Wired Location Service
Configuring LLDP, LLDP-MED, and Wired Location Service
Configuring LLDP, LLDP-MED, and Wired Location Service
• Default LLDP Configuration, page 1-5
• Configuration Guidelines, page 1-5
• Enabling LLDP, page 1-6
• Configuring LLDP Characteristics, page 1-6
• Configuring LLDP-MED TLVs, page 1-7
• Configuring Network-Policy TLV, page 1-8
• Configuring Location TLV and Wired Location Service, page 1-10
Default LLDP Configuration
Configuration Guidelines
• If the interface is configured as a tunnel port, LLDP is automatically disabled.
• If you first configure a network-policy profile on an interface, you cannot apply the switchport
voice vlan command on the interface. If the switchport voice vlan vlan-id is already configured on
an interface, you can apply a network-policy profile on the interface. This way the interface has the
voice or voice-signaling VLAN network-policy profile applied on the interface.
• You cannot configure static secure MAC addresses on an interface that has a network-policy profile.
• You cannot configure a network-policy profile on a private-VLAN port.
• For wired location to function, you must first enter the ip device tracking global configuration
command.
Table 1-1 Default LLDP Configuration
Feature Default Setting
LLDP global state Disabled
LLDP holdtime (before discarding) 120 seconds
LLDP timer (packet update frequency) 30 seconds
LLDP reinitialization delay 2 seconds
LLDP tlv-select Disabled to send and receive all TLVs
LLDP interface state Disabled
LLDP receive Disabled
LLDP transmit Disabled
LLDP med-tlv-select Disabled to send all LLDP-MED TLVs. When
LLDP is globally enabled, LLDP-MED-TLV is
also enabled.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
