Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring Private VLANs
Configuring Private VLANs
• If two stacks merge, private VLANs on the winning stack are not affected, but private-VLAN
configuration on the losing switch is lost when that switch reboots.
For more information about switch stacks, see Chapter 1, “Managing Switch Stacks.”
Configuring Private VLANs
These sections contain this configuration information:
• Tasks for Configuring Private VLANs, page 1-6
• Default Private-VLAN Configuration, page 1-6
• Private-VLAN Configuration Guidelines, page 1-7
• Configuring and Associating VLANs in a Private VLAN, page 1-10
• Configuring a Layer 2 Interface as a Private-VLAN Host Port, page 1-11
• Configuring a Layer 2 Interface as a Private-VLAN Promiscuous Port, page 1-13
• Mapping Secondary VLANs to a Primary VLAN Layer 3 VLAN Interface, page 1-13
Tasks for Configuring Private VLANs
To configure a private VLAN, perform these steps:
Step 1 Set VTP mode to transparent.
Step 2 Create the primary and secondary VLANs and associate them. See the “Configuring and Associating
VLANs in a Private VLAN” section on page 1-10.
Note If the VLAN is not created already, the private-VLAN configuration process creates it.
Step 3 Configure interfaces to be isolated or community host ports, and assign VLAN membership to the host
port. See the “Configuring a Layer 2 Interface as a Private-VLAN Host Port” section on page 1-11.
Step 4 Configure interfaces as promiscuous ports, and map the promiscuous ports to the primary-secondary
VLAN pair. See the “Configuring a Layer 2 Interface as a Private-VLAN Promiscuous Port” section on
page 1-13.
Step 5 If inter-VLAN routing will be used, configure the primary SVI, and map secondary VLANs to the
primary. See the “Mapping Secondary VLANs to a Primary VLAN Layer 3 VLAN Interface” section on
page 1-13.
Step 6 Verify private-VLAN configuration.
Default Private-VLAN Configuration
No private VLANs are configured.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
