Cisco Catalyst 3560-X User Manual

1-2
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring CDP
Configuring CDP
For a switch and connected endpoint devices running Cisco Medianet
• CDP identifies connected endpoints that communicate directly with the switch.
• To prevent duplicate reports of neighboring devices, only one wired switch reports the location
information.
• The wired switch and the endpoints both send and receive location information.
For information:
http://www.cisco.com/en/US/docs/ios/netmgmt/configuration/guide/nm_cdp_discover.html.
The switch supports CDP Version 2.
CDP and Switch Stacks
A switch stack appears as a single switch in the network. Therefore, CDP discovers the switch stack, not
the individual stack members. The switch stack sends CDP messages to neighboring network devices
when there are changes to the switch stack membership, such as stack members being added or removed.
Configuring CDP
• Default CDP Configuration, page 1-2
• Configuring the CDP Characteristics, page 1-2
• Disabling and Enabling CDP, page 1-3
• Disabling and Enabling CDP on an Interface, page 1-4
Default CDP Configuration
Configuring the CDP Characteristics
You can configure the frequency of CDP updates, the amount of time to hold the information before
discarding it, and whether or not to send Version-2 advertisements.
Table 1-1 Default CDP Configuration
Feature Default Setting
CDP global state Enabled
CDP interface state Enabled
CDP timer (packet update frequency) 60 seconds
CDP holdtime (before discarding) 180 seconds
CDP Version-2 advertisements Enabled

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
