Chapter 1 Configuring Fallback Bridging
Configuring Fallback Bridging
Fallback Bridging and Switch Stacks
When the stack master fails, a stack member becomes the new stack master by using the election process
described in Chapter 1, “Managing Switch Stacks.” The new stack master creates new VLAN-bridge
spanning-tree instance, which temporarily puts the spanning-tree ports used for fallback bridging into a
nonforwarding state. A momentary traffic disruption occurs until the spanning-tree states transition to
the forwarding state. All MAC addresses must be relearned in the bridge group.
Note If a stack master running the IP services feature set fails and if the newly elected stack master is running
the IP base feature set, the switch stack loses its fallback bridging capability.
If stacks merge or if a switch is added to the stack, any new VLANs that are part of a bridge group and
become active are included in the VLAN-bridge STP.
When a stack member fails, the addresses learned from this member are deleted from the bridge group
MAC address table.
For more information about switch stacks, see Chapter 1, “Managing Switch Stacks.”
Configuring Fallback Bridging
• Default Fallback Bridging Configuration, page 1-3
• Fallback Bridging Configuration Guidelines, page 1-4
• Creating a Bridge Group, page 1-4 (required)
• Adjusting Spanning-Tree Parameters, page 1-5 (optional)
Default Fallback Bridging Configuration
Table 1-1 Default Fallback Bridging Configuration
Feature Default Setting
Bridge groups None are defined or assigned to a port. No
VLAN-bridge STP is defined.
Switch forwards frames for stations that it has
dynamically learned
Enabled.
Spanning tree parameters:
• Switch priority
• Port priority
• Port path cost
• Hello BPDU interval
• Forward-delay interval
• Maximum idle interval
• 32768.
• 128.
• 10 Mb/s: 100.
100 Mb/s: 19.
1000 Mb/s: 4.
• 2 seconds.
• 20 seconds.
• 30 seconds.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
