Cisco Catalyst 3560-X User Manual

1-12
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring DHCP Features and IP Source Guard
Configuring DHCP Features
To remove the DHCP packet forwarding address, use the no ip helper-address address interface
configuration command.
Enabling DHCP Snooping and Option 82
Beginning in privileged EXEC mode, follow these steps to enable DHCP snooping on the switch:
Step 6
interface range port-range
or
interface interface-id
Configure multiple physical ports that are connected
to the DHCP clients, and enter interface range
configuration mode.
or
Configure a single physical port that is connected to
the DHCP client, and enter interface configuration
mode.
Step 7
switchport mode access Define the VLAN membership mode for the port.
Step 8
switchport access vlan vlan-id Assign the ports to the same VLAN as configured in
Step 2.
Step 9
end Return to privileged EXEC mode.
Step 10
show running-config Verify your entries.
Step 11
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
ip dhcp snooping Enable DHCP snooping globally.
Step 3
ip dhcp snooping vlan vlan-range
[smartlog]
Enable DHCP snooping on a VLAN or range of VLANs. The range is 1
to 4094.
• You can enter a single VLAN ID identified by VLAN ID number, a
series of VLAN IDs separated by commas, a range of VLAN IDs
separated by hyphens, or a range of VLAN IDs separated by entering
the starting and ending VLAN IDs separated by a space.
• (Optional) Enter smartlog to configure the switch to send the
contents of dropped packets to a NetFlow collector.
Step 4
ip dhcp snooping information option Enable the switch to insert and remove DHCP relay information
(option-82 field) in forwarded DHCP request messages to the DHCP
server. This is the default setting.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
