Cisco Catalyst 3560-X User Manual

1-12
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring IP Unicast Routing
Configuring IP Addressing
Beginning in privileged EXEC mode, follow these steps to specify the ARP encapsulation type:
To disable an encapsulation type, use the no arp arpa or no arp snap interface configuration command.
Enable Proxy ARP
By default, the switch uses proxy ARP to help hosts learn MAC addresses of hosts on other networks or
subnets.
Beginning in privileged EXEC mode, follow these steps to enable proxy ARP if it has been disabled:
To disable proxy ARP on the interface, use the no ip proxy-arp interface configuration command.
Routing Assistance When IP Routing is Disabled
These mechanisms allow the switch to learn about routes to other networks when it does not have IP
routing enabled:
• Proxy ARP, page 1-13
• Default Gateway, page 1-13
• ICMP Router Discovery Protocol (IRDP), page 1-13
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Enter interface configuration mode, and specify the Layer 3
interface to configure.
Step 3
arp {arpa | snap} Specify the ARP encapsulation method:
• arpa—Address Resolution Protocol
• snap—Subnetwork Address Protocol
Step 4
end Return to privileged EXEC mode.
Step 5
show interfaces [interface-id] Verify ARP encapsulation configuration on all interfaces or
the specified interface.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Enter interface configuration mode, and specify the Layer 3
interface to configure.
Step 3
ip proxy-arp Enable proxy ARP on the interface.
Step 4
end Return to privileged EXEC mode.
Step 5
show ip interface [interface-id] Verify the configuration on the interface or all interfaces.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
