1-3
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring CDP
Configuring CDP
Beginning in privileged EXEC mode, follow these steps to configure the CDP timer, holdtime, and
advertisement type.
Note Steps 2 through 4 are all optional and can be performed in any order.
Use the no form of the CDP commands to return to the default settings.
This example shows how to configure CDP characteristics.
Switch# configure terminal
Switch(config)# cdp timer 50
Switch(config)# cdp holdtime 120
Switch(config)# cdp advertise-v2
Switch(config)# end
For additional CDP show commands, see the “Monitoring and Maintaining CDP” section on page 1-5.
Disabling and Enabling CDP
CDP is enabled by default.
Note Switch clusters and other Cisco devices (such as Cisco IP Phones) regularly exchange CDP messages.
Disabling CDP can interrupt cluster discovery and device connectivity. For more information, see
Chapter 1, “Clustering Switches” and see Getting Started with Cisco Network Assistant, available on
Cisco.com.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
cdp timer seconds (Optional) Set the transmission frequency of CDP updates in seconds.
The range is 5 to 254; the default is 60 seconds.
Step 3
cdp holdtime seconds (Optional) Specify the amount of time a receiving device should hold the
information sent by your device before discarding it.
The range is 10 to 255 seconds; the default is 180 seconds.
Step 4
cdp advertise-v2 (Optional) Configure CDP to send Version-2 advertisements.
This is the default state.
Step 5
end Return to privileged EXEC mode.
Step 6
show cdp Verify your settings.
Step 7
copy running-config startup-config (Optional) Save your entries in the configuration file.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
