Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring IP Unicast Routing
Configuring OSPF
Default OSPF Configuration
Table 1-5 Default OSPF Configuration
Feature Default Setting
Interface parameters Cost: No default cost predefined.
Retransmit interval: 5 seconds.
Transmit delay: 1 second.
Priority: 1.
Hello interval: 10 seconds.
Dead interval: 4 times the hello interval.
No authentication.
No password specified.
MD5 authentication disabled.
Area Authentication type: 0 (no authentication).
Default cost: 1.
Range: Disabled.
Stub: No stub area defined.
NSSA: No NSSA area defined.
Auto cost 100 Mb/s.
Default-information originate Disabled. When enabled, the default metric setting is 10, and the external route type
default is Type 2.
Default metric Built-in, automatic metric translation, as appropriate for each routing protocol.
Distance OSPF dist1 (all routes within an area): 110.
dist2 (all routes from one area to another): 110.
and dist3 (routes from other routing domains): 110.
OSPF database filter Disabled. All outgoing link-state advertisements (LSAs) are flooded to the interface.
IP OSPF name lookup Disabled.
Log adjacency changes Enabled.
Neighbor None specified.
Neighbor database filter Disabled. All outgoing LSAs are flooded to the neighbor.
Network area Disabled.
NSF
1
awareness Enabled
2
. Allows Layer 3 switches to continue forwarding packets from a neighboring
NSF-capable router during hardware or software changes.
NSF capability Disabled.
Note The switch stack supports OSPF NSF-capable routing for IPv4.
Router ID No OSPF routing process defined.
Summary address Disabled.
Timers LSA group pacing 240 seconds.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
