Cisco Catalyst 3560-X User Manual

1-8
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring IPv6 MLD Snooping
Configuring IPv6 MLD Snooping
Configuring a Static Multicast Group
Hosts or Layer 2 ports normally join multicast groups dynamically, but you can also statically configure
an IPv6 multicast address and member ports for a VLAN.
Beginning in privileged EXEC mode, follow these steps to add a Layer 2 port as a member of a multicast
group:
To remove a Layer 2 port from the multicast group, use the no ipv6 mld snooping vlan vlan-id static
mac-address interface interface-id global configuration command. If all member ports are removed
from a group, the group is deleted.
This example shows how to statically configure an IPv6 multicast group:
Switch# configure terminal
Switch(config)# ipv6 mld snooping vlan 2 static FF12::3 interface gigabitethernet0/1
Switch(config)# end
Configuring a Multicast Router Port
Although MLD snooping learns about router ports through MLD queries and PIMv6 queries, you can
also use the command-line interface (CLI) to add a multicast router port to a VLAN. To add a multicast
router port (add a static connection to a multicast router), use the ipv6 mld snooping vlan mrouter
global configuration command on the switch.
Note Static connections to multicast routers are supported only on switch ports.
Command Purpose
Step 1
configure terminal Enter global configuration mode
Step 2
ipv6 mld snooping vlan vlan-id static
ipv6_multicast_address interface interface-id
Statically configure a multicast group with a Layer 2 port as a
member of a multicast group:
• vlan-id is the multicast group VLAN ID. The VLAN ID
range is 1 to 1001 and 1006 to 4094.
• ipv6_multicast_address is the 128-bit group IPv6 address.
The address must be in the form specified in RFC 2373.
• interface-id is the member port. It can be a physical
interface or a port channel (1 to 48).
Step 3
end Return to privileged EXEC mode.
Step 4
show ipv6 mld snooping address user
or
show ipv6 mld snooping address vlan vlan-id
user
Verify the static member port and the IPv6 address.
Step 5
copy running-config startup-config (Optional) Save your entries in the configuration file.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
