1-15
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring IEEE 802.1x Port-Based Authentication
Understanding IEEE 802.1x Port-Based Authentication
AV pairs are automatically sent by a switch that is configured for 802.1x accounting. Three types of
RADIUS accounting packets are sent by a switch:
• START–sent when a new user session starts
• INTERIM–sent during an existing session for updates
• STOP–sent when a session terminates
Table 1-3 lists the AV pairs and when they are sent are sent by the switch:
You can view the AV pairs that are being sent by the switch by entering the debug radius accounting
privileged EXEC command. For more information about this command, see the Cisco IOS Debug
Command Reference, Release 12.4.
For more information about AV pairs, see RFC 3580, “IEEE 802.1x Remote Authentication Dial In User
Service (RADIUS) Usage Guidelines.”
802.1x Readiness Check
The 802.1x readiness check monitors 802.1x activity on all the switch ports and displays information
about the devices connected to the ports that support 802.1x. You can use this feature to determine if the
devices connected to the switch ports are 802.1x-capable. You use an alternate authentication such as
MAC authentication bypass or web authentication for the devices that do not support 802.1x
functionality.
Table 1-3 Accounting AV Pairs
Attribute Number AV Pair Name START INTERIM STOP
Attribute[1] User-Name Always Always Always
Attribute[4] NAS-IP-Address Always Always Always
Attribute[5] NAS-Port Always Always Always
Attribute[8] Framed-IP-Address Never Sometimes
1
1. The Framed-IP-Address AV pair is sent only if a valid Dynamic Host Control Protocol (DHCP) binding
exists for the host in the DHCP snooping bindings table.
Sometimes
1
Attribute[25] Class Always Always Always
Attribute[30] Called-Station-ID Always Always Always
Attribute[31] Calling-Station-ID Always Always Always
Attribute[40] Acct-Status-Type Always Always Always
Attribute[41] Acct-Delay-Time Always Always Always
Attribute[42] Acct-Input-Octets Never Always Always
Attribute[43] Acct-Output-Octets Never Always Always
Attribute[44] Acct-Session-ID Always Always Always
Attribute[45] Acct-Authentic Always Always Always
Attribute[46] Acct-Session-Time Never Always Always
Attribute[49] Acct-Terminate-Cause Never Never Always
Attribute[61] NAS-Port-Type Always Always Always
