1-26
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Managing Switch Stacks
Configuring the Switch Stack
WARNING: not appear elsewhere in this network domain. If it does,
WARNING: user traffic may be blackholed.
Switch(config)# end
Switch# show switch
Switch/Stack Mac Address : 0016.4727.a900
Mac persistency wait time: 7 mins
H/W Current
Switch# Role Mac Address Priority Version State
----------------------------------------------------------
*1 Master 0016.4727.a900 1 0 Ready
Assigning Stack Member Information
These sections describe how to assign stack member information:
Assigning a Stack Member Number, page 1-26 (optional)
Setting the Stack Member Priority Value, page 1-26 (optional)
Provisioning a New Member for a Switch Stack, page 1-27 (optional)
Assigning a Stack Member Number
Note This task is available only from the stack master.
Beginning in privileged EXEC mode, follow these steps to assign a member number to a stack member.
This procedure is optional.
Setting the Stack Member Priority Value
Note This task is available only from the stack master.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
switch current-stack-member-number
renumber new-stack-member-number
Specify the current stack member number and the new stack member
number for the stack member. The range is 1 to 9.
You can display the current stack member number by using the show
switch user EXEC command.
Step 3
end Return to privileged EXEC mode.
Step 4
reload slot stack-member-number Reset the stack member.
Step 5
show switch Verify the stack member number.
Step 6
copy running-config startup-config Save your entries in the configuration file.
