Cisco Catalyst 3560-X User Manual

1-22
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring IP Unicast Routing
Configuring RIP
Configuring Basic RIP Parameters
Note To configure RIP, you enable RIP routing for a network and optionally configure other parameters. On
the Catalyst 3750-X and 3560-X switches, RIP configuration commands are ignored until you configure
the network number.
Beginning in privileged EXEC mode, follow these steps to enable and configure RIP:
Timers basic
• Update: 30 seconds.
• Invalid: 180 seconds.
• Hold-down: 180 seconds.
• Flush: 240 seconds.
Validate-update-source Enabled.
Version Receives RIP Version 1 and 2 packets; sends Version 1 packets.
Table 1-4 Default RIP Configuration (continued)
Feature Default Setting
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
ip routing Enable IP routing. (Required only if IP routing is disabled.)
Step 3
router rip Enable a RIP routing process, and enter router configuration mode.
Step 4
network network number Associate a network with a RIP routing process. You can specify multiple
network commands. RIP routing updates are sent and received through
interfaces only on these networks.
Note You must configure a network number for the RIP commands to
take effect.
Step 5
neighbor ip-address (Optional) Define a neighboring router with which to exchange routing
information. This step allows routing updates from RIP (normally a
broadcast protocol) to reach nonbroadcast networks.
Step 6
offset list [access-list number | name]
{in | out} offset [type number]
(Optional) Apply an offset list to routing metrics to increase incoming
and outgoing metrics to routes learned through RIP. You can limit the
offset list with an access list or an interface.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
