1-33
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Managing Switch Stacks
Troubleshooting Stacks
Identifying Loopback Problems
Software Loopback, page 1-34
Software Loopback Example: No Connected Stack Cable, page 1-35
Software Loopback Examples: Connected Stack Cables, page 1-35
Hardware Loopback, page 1-36
Hardware Loopback Example: LINK OK event, page 1-36
Hardware Loop Example: LINK NOT OK Event, page 1-37
Link OK This shows if the link is stable.
The link partner is a stack port on a neighbor switch.
No—The link partner receives invalid protocol messages from the
port.
Yes—The link partner receives valid protocol messages from the
port.
Link Active This shows if the stack port is in the same state as its link partner.
No—The port cannot send traffic to the link partner.
Yes—The port can send traffic to the link partner.
Sync OK
No—The link partner does not send valid protocol messages to the
stack port.
Yes—The link partner sends valid protocol messages to the port.
# Changes to LinkOK This shows the relative stability of the link.
If a large number of changes occur in a short period of time, link flapping
can occur.
In Loopback
No—At least one stack port on the member has an attached stack
cable.
Yes—None of the stack ports on the member has an attached stack
cable.
Table 1-5 show switch stack-ports summary Command Output (continued)
Field Description
