1-14
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring System Message Logging and Smart Logging
Configuring Smart Logging
To remove a syslog server, use the no logging host global configuration command, and specify the syslog
server IP address. To disable logging to syslog servers, enter the no logging trap global configuration
command.
Table 1-4 lists the UNIX system facilities supported by the software. For more information about these
facilities, consult the operator’s manual for your UNIX operating system.
Configuring Smart Logging
Smart logging provides a mechanism to capture and export packet flows based on predefined or
user-configured triggers. Beginning with Cisco IOS Release 12.2(58)SE, the switch supports smart
logging for these events:
DHCP snooping violations
Dynamic ARP inspection violations
IP source guard denied traffic
ACL permitted or denied traffic
To use smart logging, you must first configure a NetFlow exporter that you identify when you enable
smart logging. For information on configuring Cisco Flexible NetFlow, see the Cisco IOS Flexible
NetFlow Configuration Guide, Release 12.4T:
http://www.cisco.com.do/en/US/docs/ios/fnetflow/configuration/guide/12_4t/fnf_12_4t_book.html
Step 6
show running-config Verify your entries.
Step 7
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Table 1-4 Logging Facility-Type Keywords
Facility Type Keyword Description
auth Authorization system
cron Cron facility
daemon System daemon
kern Kernel
local0-7 Locally defined messages
lpr Line printer system
mail Mail system
news USENET news
sys9-14 System use
syslog System log
user User process
uucp UNIX-to-UNIX copy system
