1-26
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring IPv6 Unicast Routing
Configuring IPv6
To disable IPv4 routing, use the no ip routing global configuration command. To disable IPv6 routing,
use the no ipv6 unicast-routing global configuration command. To remove an IPv4 address from an
interface, use the no ip address ip-address mask interface configuration command. To remove an IPv6
address from an interface, use the no ipv6 address ipv6-prefix/prefix length eui-64 or no ipv6 address
ipv6-address link-local interface configuration command. To remove all manually configured IPv6
addresses from an interface, use the no ipv6 address interface configuration command without
arguments. To disable IPv6 processing on an interface that has not been explicitly configured with an
IPv6 address, use the no ipv6 enable interface configuration command.
This example shows how to enable IPv4 and IPv6 routing on an interface.
Switch(config)# sdm prefer dual-ipv4-and-ipv6 default
Switch(config)# ip routing
Switch(config)# ipv6 unicast-routing
Switch(config)# interface fastethernet1/0/11
Switch(config-if)# no switchport
Switch(config-if)# ip address 192.168.99.1 244.244.244.0
Switch(config-if)# ipv6 address 2001:0DB8:c18:1::/64 eui 64
Switch(config-if)# end
Configuring DHCP for IPv6 Address Assignment
• Default DHCPv6 Address Assignment Configuration, page 1-27
• DHCPv6 Address Assignment Configuration Guidelines, page 1-27
• Enabling DHCPv6 Server Function, page 1-27
• Enabling DHCPv6 Client Function, page 1-29
Step 7
ipv6 address ipv6-prefix/prefix length eui-64
or
ipv6 address ipv6-address link-local
or
ipv6 enable
Specify a global IPv6 address. Specify only the network prefix;
the last 64 bits are automatically computed from the switch
MAC address.
Specify a link-local address on the interface to be used instead
of the automatically configured link-local address when IPv6 is
enabled on the interface.
Automatically configure an IPv6 link-local address on the
interface, and enable the interface for IPv6 processing. The
link-local address can only be used to communicate with nodes
on the same link.
Step 8
end Return to privileged EXEC mode.
Step 9
show interface interface-id
show ip interface interface-id
show ipv6 interface interface-id
Verify your entries.
Step 10
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
