Cisco Catalyst 3560-X User Manual

1-12
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring SPAN and RSPAN
Configuring SPAN and RSPAN
Configuring SPAN and RSPAN
• Default SPAN and RSPAN Configuration, page 1-12
• Configuring Local SPAN, page 1-12
• Configuring RSPAN, page 1-17
Default SPAN and RSPAN Configuration
Configuring Local SPAN
• SPAN Configuration Guidelines, page 1-12
• Creating a Local SPAN Session, page 1-13
• Creating a Local SPAN Session and Configuring Incoming Traffic, page 1-15
• Specifying VLANs to Filter, page 1-16
SPAN Configuration Guidelines
• On each switch stack, you can configure a maximum of 2 source sessions and 64 RSPAN destination
sessions. A source session is either a local SPAN session or an RSPAN source session.
• For SPAN sources, you can monitor traffic for a single port or VLAN or a series or range of ports
or VLANs for each session. You cannot mix source ports and source VLANs within a single SPAN
session.
• The destination port cannot be a source port; a source port cannot be a destination port.
• You cannot have two SPAN sessions using the same destination port.
• When you configure a switch port as a SPAN destination port, it is no longer a normal switch port;
only monitored traffic passes through the SPAN destination port.
• Entering SPAN configuration commands does not remove previously configured SPAN parameters.
You must enter the no monitor session {session_number | all | local | remote} global configuration
command to delete configured SPAN parameters.
Table 1-1 Default SPAN and RSPAN Configuration
Feature Default Setting
SPAN state (SPAN and RSPAN) Disabled.
Source port traffic to monitor Both received and sent traffic (both).
Encapsulation type (destination port) Native form (untagged packets).
Ingress forwarding (destination port) Disabled
VLAN filtering On a trunk interface used as a source port, all VLANs are
monitored.
RSPAN VLANs None configured.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
