Page #1218 background imageLoading...
Page #1218 background image
1-10
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring Cisco IOS IP SLAs Operations
Configuring IP SLAs Operations
To disable the IP SLAs operation, enter the no ip sla operation-number global configuration command.
This example shows how to configure a UDP jitter IP SLAs operation:
Switch(config)# ip sla 10
Switch(config-ip-sla)# udp-jitter 172.29.139.134 5000
Switch(config-ip-sla-jitter)# frequency 30
Switch(config-ip-sla-jitter)# exit
Switch(config)# ip sla schedule 5 start-time now life forever
Switch(config)# end
Switch# show ip sla configuration 10
IP SLAs, Infrastructure Engine-II.
Entry number: 10
Owner:
Tag:
Type of operation to perform: udp-jitter
Target address/Source address: 1.1.1.1/0.0.0.0
Target port/Source port: 2/0
Request size (ARR data portion): 32
Operation timeout (milliseconds): 5000
Packet Interval (milliseconds)/Number of packets: 20/10
Type Of Service parameters: 0x0
Verify data: No
Vrf Name:
Control Packets: enabled
Step 6
ip sla monitor schedule
operation-number [life {forever |
seconds}] [start-time {hh:mm [:ss]
[month day | day month] | pending
| now | after hh:mm:ss] [ageout
seconds] [recurring]
Configure the scheduling parameters for an individual IP SLAs operation.
operation-number—Enter the RTR entry number.
(Optional) life—Set the operation to run indefinitely (forever) or for a
specific number of seconds. The range is from 0 to 2147483647. The
default is 3600 seconds (1 hour).
(Optional) start-time—Enter the time for the operation to begin collecting
information:
To start at a specific time, enter the hour, minute, second (in 24-hour
notation), and day of the month. If no month is entered, the default is
the current month.
Enter pending to select no information collection until a start time is
selected.
Enter now to start the operation immediately.
Enter after hh:mm:ss to show that the operation should start after the
entered time has elapsed.
(Optional) ageout seconds—Enter the number of seconds to keep the
operation in memory when it is not actively collecting information. The
range is 0 to 2073600 seconds, the default is 0 seconds (never ages out).
(Optional) recurring—Set the operation to automatically run every day.
Step 7
end Return to privileged EXEC mode.
Step 8
show ip sla configuration
[operation-number]
(Optional) Display configuration values, including all defaults for all IP SLAs
operations or a specified operation.
Step 9
copy running-config
startup-config
(Optional) Save your entries in the configuration file.
