Chapter 1 Managing Switch Stacks
Configuring the Switch Stack
To remove provisioned information and to avoid receiving an error message, remove the specified switch
from the stack before you use the no form of this command.
For example, if you are removing a provisioned switch in a stack with this configuration:
• The stack has four members
• Stack member 1 is the master
• Stack member 3 is a provisioned switch
and want to remove the provisioned information and to avoid receiving an error message, you can remove
power from stack member 3, disconnect the StackWise Plus cables between the stack member 3 and
switches to which it is connected, reconnect the cables between the remaining stack members, and enter
the no switch stack-member-number provision global configuration command.
This example shows how to provision a switch with a stack member number of 2 for the switch stack.
The show running-config command output shows the interfaces associated with the provisioned switch:
Switch(config)# switch 2 provision switch_PID
Switch(config)# end
Switch# show running-config | include switch 2
!
interface GigabitEthernet2/0/1
!
interface GigabitEthernet2/0/2
!
interface GigabitEthernet2/0/3
<output truncated>
Running a Rolling Stack Update
Beginning in privileged EXEC mode:
Command Purpose
Step 1
configure terminal Enters global configuration mode.
Step 2
boot time minutes (Optional) Sets the stack boot time in minutes.
The range is from 7 to 30.
The default is 7.
Step 3
interface interface-id Specifies the port and enters interface configuration mode.
Step 4
rsu {active | standby} On a member, configures half of the redundant uplink to the network,
and assigns one of these roles to a member interface.
• active—Sets the interface to active.
• standby—Sets the interface to standby.
Note If spanning tree protocol (STP) is enabled, set the standby role
to the blocked interface.
By default, the role is not set.
Step 5
interface interface-id Specifies the port on another member, and enters interface configuration
mode.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
