Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring IEEE 802.1x Port-Based Authentication
Configuring 802.1x Authentication
• Resetting the 802.1x Authentication Configuration to the Default Values, page 1-76 (optional)
Default 802.1x Authentication Configuration
Table 1-4 Default 802.1x Authentication Configuration
Feature Default Setting
Switch 802.1x enable state Disabled.
Per-port 802.1x enable state Disabled (force-authorized).
The port sends and receives normal traffic without 802.1x-based
authentication of the client.
AAA Disabled.
RADIUS server
• IP address
• UDP authentication port
• Key
• None specified.
• 1812.
• None specified.
Host mode Single-host mode.
Control direction Bidirectional control.
Periodic re-authentication Disabled.
Number of seconds between re-authentication
attempts
3600 seconds.
Re-authentication number 2 times (number of times that the switch restarts the authentication process
before the port changes to the unauthorized state).
Quiet period 60 seconds (number of seconds that the switch remains in the quiet state
following a failed authentication exchange with the client).
Retransmission time 30 seconds (number of seconds that the switch should wait for a response to
an EAP request/identity frame from the client before resending the request).
Maximum retransmission number 2 times (number of times that the switch will send an EAP-request/identity
frame before restarting the authentication process).
Client timeout period 30 seconds (when relaying a request from the authentication server to the
client, the amount of time the switch waits for a response before resending the
request to the client.)
Authentication server timeout period 30 seconds (when relaying a response from the client to the authentication
server, the amount of time the switch waits for a reply before resending the
response to the server.)
You can change this timeout period by using the dot1x timeout
server-timeout interface configuration command.
Guest VLAN None specified.
Inaccessible authentication bypass Disabled.
Restricted VLAN None specified.
Authenticator (switch) mode None specified.
MAC authentication bypass Disabled.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
