Chapter 1 Configuring MACsec Encryption
Configuring Cisco TrustSec MACsec
This example shows how to configure Cisco TrustSec authentication in manual mode on an interface:
Switch# configure terminal
Switch(config)# interface tengiigabitethernet 1/1/2
Switch(config-if)# cts manual
Switch(config-if-cts-manual)# sap pmk 1234abcdef mode-list gcm-encrypt null no-encap
Switch(config-if-cts-manual)# no propagate sgt
Switch(config-if-cts-manual)# exit
Switch(config-if)# end
Step 4
sap pmk key [mode-list mode1 [mode2 [mode3
[mode4]]]]
(Optional) Configures the SAP pairwise master key (PMK) and
operation mode. SAP is disabled by default in Cisco TrustSec
manual mode.
• key—A hexadecimal value with an even number of characters
and a maximum length of 32 characters.
The SAP operation mode options:
• gcm-encrypt—Authentication and encryption
Note Select this mode for MACsec authentication and
encryption if your software license supports MACsec
encryption.
• gmac—Authentication, no encryption
• no-encap—No encapsulation
• null—Encapsulation, no authentication or encryption
Note If the interface is not capable of data link encryption,
no-encap is the default and the only available SAP
operating mode. SGT is not supported.
Step 5
no propagate sgt Use the no form of this command when the peer is incapable of
processing a SGT. The no propagate sgt command prevents the
interface from transmitting the SGT to the peer and is required in
manual mode.
Step 6
exit Exits Cisco TrustSec 802.1X interface configuration mode.
Step 7
end Returns to privileged EXEC mode.
Step 8
show cts interface [interface-id | brief |
summary]
(Optional) Verify the configuration by displaying
TrustSec-related interface characteristics.
Step 9
copy running-config startup-config (Optional) Saves your entries in the configuration file.
Command Purpose

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
