Cisco Catalyst 3560-X User Manual

1-45
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring Interface Characteristics
Configuring the System MTU
If you enter a value that is outside the allowed range for the specific type of interface, the value is not
accepted.
This example shows how to set the maximum packet size for a Gigabit Ethernet port to 7500 bytes:
Switch(config)# system mtu jumbo 7500
Switch(config)# exit
Switch# reload
This example shows the response when you try to set Gigabit Ethernet interfaces to an out-of-range
number:
Switch(config)# system mtu jumbo 25000
^
% Invalid input detected at '^' marker.
Step 4
system mtu bytes (Optional) In a mixed hardware stack, change the MTU
size for all Fast Ethernet interfaces on the Catalyst 3750
members.
The range is 1500 to 1998 bytes; the default is
1500 bytes.
Note This command does not apply to
Catalyst 3560-X switches.
Step 5
end Returns to privileged EXEC mode.
Step 6
copy running-config startup-config Saves your entries in the configuration file.
Step 7
reload Reloads the operating system.
Step 8
show system mtu Verifies your settings.
Command Purpose

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
