Chapter 1 Configuring DHCP Features and IP Source Guard
Configuring IP Source Guard
This example shows how to stop IPSG with static hosts on an interface.
Switch(config-if)# no ip verify source
Switch(config-if)# no ip device tracking max
This example shows how to enable IPSG with static hosts on a port.
Switch(config)# ip device tracking
Switch(config)# ip device tracking max 10
Switch(config-if)# ip verify source tracking port-security
This example shows how to enable IPSG for static hosts with IP filters on a Layer 2 access port and to
verify the valid IP bindings on the interface Gi1/0/3:
Switch# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# ip device tracking
Switch(config)# interface gigabitethernet1/0/3
Switch(config-if)# switchport mode access
Switch(config-if)# switchport access vlan 10
Switch(config-if)# ip device tracking maximum 5
Switch(config-if)# ip verify source tracking
Switch(config-if)# end
Switch# show ip verify source
Interface Filter-type Filter-mode IP-address Mac-address Vlan
--------- ----------- ----------- --------------- ----------------- ----
Gi1/0/3 ip trk active 40.1.1.24 10
Gi1/0/3 ip trk active 40.1.1.20 10
Gi1/0/3 ip trk active 40.1.1.21 10
This example shows how to enable IPSG for static hosts with IP-MAC filters on a Layer 2 access port,
to verify the valid IP-MAC bindings on the interface Gi1/0/3, and to verify that the number of bindings
on this interface has reached the maximum:
Switch# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# ip device tracking
Switch(config)# interface gigabitethernet1/0/3
Switch(config-if)# switchport mode access
Switch(config-if)# switchport access vlan 1
Switch(config-if)# ip device tracking maximum 5
Switch(config-if)# switchport port-security
Switch(config-if)# switchport port-security maximum 5
Switch(config-if)# ip verify source tracking port-security
Switch(config-if)# end
Step 11
show ip verify source interface interface-id Verify the configuration and display IPSG permit ACLs
for static hosts.
Step 12
show ip device track all
[active | inactive] count
Verify the configuration by displaying the IP-to-MAC
binding for a given host on the switch interface.
• all active—display only the active IP or MAC
binding entries
• all inactive—display only the inactive IP or MAC
binding entries
• all—display the active and inactive IP or MAC
binding entries
Command Purpose

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
