Cisco Catalyst 3750-X User Manual

42-24
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-21521-01
Chapter 42 Configuring IP Unicast Routing
Configuring RIP
If you want to configure an interface running RIP to advertise a summarized local IP address pool on a
network access server for dial-up clients, use the ip summary-address rip interface configuration
command.
Note If split horizon is enabled, neither autosummary nor interface IP summary addresses are advertised.
Beginning in privileged EXEC mode, follow these steps to
set an interface to advertise a summarized
local IP address and to disable split horizon on the interface:
To disable IP summarization, use the no ip summ
ary-address rip router configuration command.
In this example, the major net is
10.0.0.0. The summary address 10.2.0.0 overrides the autosummary
address of 10.0.0.0 so that 10.2.0.0 is advertised out interface Gigabit Ethernet port 2, and 10.0.0.0 is
not advertised. In the example, if the interface is still in Layer 2 mode (the default), you must enter a no
switchport interface configuration command before entering the ip address interface configuration
command.
Note If split horizon is enabled, neither autosummary nor interface summary addresses (those configured with
the ip summary-address rip router configuration command) are advertised.
Switch(config)# router rip
Switch(config-router)# interface
gigabitethernet1/0/2
Switch(config-if)# ip address 10.
1.5.1 255.255.255.0
Switch(config-if)# ip summary-add
ress rip 10.2.0.0 255.255.0.0
Switch(config-if)# no ip split-ho
rizon
Switch(config-if)# exit
Switch(config)# router rip
Switch(config-router)# network 10
.0.0.0
Switch(config-router)# neighbor 2
.2.2.2 peer-group mygroup
Switch(config-router)# end
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Enter interface configuration mode, and specify the Layer 3
interface to configure.
Step 3
ip address ip-address subnet-mask Configure the IP address and IP subnet.
Step 4
ip summary-address rip ip address ip-network mask Configure the IP address to be summarized and the IP
network mask.
Step 5
no ip split horizon Disable split horizon on the interface.
Step 6
end Return to privileged EXEC mode.
Step 7
show ip interface interface-id Verify your entries.
Step 8
copy running-config startup-config (Optional) Save your entries in the configuration file.

Cisco Catalyst 3750-X Specifications

General

Switching Capacity	160 Gbps
Stacking Bandwidth	64 Gbps
Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
Form Factor	Rack-mountable
DRAM	256 MB
Flash Memory	64 MB
Model	Cisco Catalyst 3750-X Series
Ports	24 or 48 10/100/1000 Ethernet ports
Uplink Interfaces	4 SFP or 2 SFP+
Features	StackWise Plus, EnergyWise
Image	IP Base or IP Services
Operating Temperature	0 to 40°C
Operating Humidity	10 to 85% noncondensing
