Cisco Catalyst 3750-X User Manual

22-18
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-21521-01
Chapter 22 Configuring Optional Spanning-Tree Features
Configuring Optional Spanning-Tree Features
Enabling Root Guard
Root guard enabled on an interface applies to all the VLANs to which the interface belongs. Do not
enable the root guard on interfaces to be used by the UplinkFast feature. With UplinkFast, the backup
interfaces (in the blocked state) replace the root port in the case of a failure. However, if root guard is
also enabled, all the backup interfaces used by the UplinkFast feature are placed in the root-inconsistent
state (blocked) and are prevented from reaching the forwarding state.
Note You cannot enable both root guard and loop guard at the same time.
You can enable this feature if your switch is running PVST+, rapid PVST+, or MSTP.
Beginning in privileged EXEC mode, follow these steps to e
nable root guard on an interface. This
procedure is optional.
To disable root guard, use the no spanni
ng-tree guard interface configuration command.
Enabling Loop Guard
You can use loop guard to prevent alternate or root ports from becoming designated ports because of a
failure that leads to a unidirectional link. This feature is most effective when it is configured on the entire
switched network. Loop guard operates only on interfaces that are considered point-to-point by the
spanning tree.
Note You cannot enable both loop guard and root guard at the same time.
You can enable this feature if your switch is running PVST+, rapid PVST+, or MSTP.
Beginning in privileged EXEC mode, follow these steps to enable loop guard. This procedure is optional.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify an interface to configure, and enter interface configuration mode.
Step 3
spanning-tree guard root Enable root guard on the interface.
By default, root guard is disabled on all interfaces.
Step 4
end Return to privileged EXEC mode.
Step 5
show running-config Verify your entries.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Step 1
show spanning-tree active
or
show spanning-tree mst
Verify which interfaces are alternate or root ports.
Step 2
configure terminal Enter global configuration mode.

Cisco Catalyst 3750-X Specifications

General

Switching Capacity	160 Gbps
Stacking Bandwidth	64 Gbps
Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
Form Factor	Rack-mountable
DRAM	256 MB
Flash Memory	64 MB
Model	Cisco Catalyst 3750-X Series
Ports	24 or 48 10/100/1000 Ethernet ports
Uplink Interfaces	4 SFP or 2 SFP+
Features	StackWise Plus, EnergyWise
Image	IP Base or IP Services
Operating Temperature	0 to 40°C
Operating Humidity	10 to 85% noncondensing
