Cisco Catalyst 3750-X User Manual

32-16
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-21521-01
Chapter 32 Configuring SPAN and RSPAN
Configuring SPAN and RSPAN
To delete a SPAN session, use the no monitor session session_number global configuration command.
To remove a source or destination port or VLAN from the SPAN session, use the no monitor session
session_number source {interface interface-id | vlan vlan-id} global configuration command or the no
monitor session session_number destination interface interface-id global configuration command. For
destination interfaces, the encapsulation and ingress options are ignored with the no form of the
command.
This example shows how to remove any existing configuration on SPAN session 2, configure SPAN
sessi
on 2 to monitor received traffic on Gigabit Ethernet source port 1, and send it to destination Gigabit
Ethernet port 2 with the same egress encapsulation type as the source port, and to enable ingress
forwarding with IEEE 802.1Q encapsulation and VLAN 6 as the default ingress VLAN.
Switch(config)# no monitor session 2
Switch(config)# monitor session 2
source gigabitethernet1/0/1 rx
Switch(config)# monit
or session 2 destination interface gigabitethernet1/0/2 encapsulation
replicate ingress dot1q vlan 6
Switch(config)# end
Specifying VLANs to Filter
Beginning in privileged EXEC mode, follow these steps to limit SPAN source traffic to specific VLANs:
Step 5
end Return to privileged EXEC mode.
Step 6
show monitor [session session_number]
show running-config
Verify the configuration.
Step 7
copy running-config startup-config (Optional) Save the configuration in the configuration file.
Command Purpose
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
no monitor session {session_number | all |
local | remote}
Remove any existing SPAN configuration for the session.
For session
_number, the range is 1 to 66.
Specify al
l to remove all SPAN sessions, local to remove all local
sessions, or remote to remove all remote SPAN sessions.
Step 3
monitor session session_number source
interface interface-id
Specify the characteristics of the source port (monitored port) and
SPAN session.
For session
_number, the range is 1 to 66.
For in
terface-id, specify the source port to monitor. The interface
specified must already be configured as a trunk port.
Step 4
monitor session session_number filter vlan
vlan-id [, | -]
Limit the SPAN source traffic to specific VLANs.
For session
_number, enter the session number specified in Step 3.
For vlan-id, the range is 1 to 4094.
(Optional) Use a comma (,) to spec
ify a series of VLANs, or use a
hyphen (-) to specify a range of VLANs. Enter a space before and after
the comma; enter a space before and after the hyphen.

Cisco Catalyst 3750-X Specifications

General

Switching Capacity	160 Gbps
Stacking Bandwidth	64 Gbps
Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
Form Factor	Rack-mountable
DRAM	256 MB
Flash Memory	64 MB
Model	Cisco Catalyst 3750-X Series
Ports	24 or 48 10/100/1000 Ethernet ports
Uplink Interfaces	4 SFP or 2 SFP+
Features	StackWise Plus, EnergyWise
Image	IP Base or IP Services
Operating Temperature	0 to 40°C
Operating Humidity	10 to 85% noncondensing
