28-13
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-21521-01
Chapter 28 Configuring Port-Based Traffic Control
Configuring Port Security
Enabling and Configuring Port Security
Beginning in privileged EXEC mode, follow these steps to restrict input to an interface by limiting and
identifying MAC addresses of the stations allowed to access the port:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the interface to be configured, and enter interface configuration
mode.
Step 3
switchport mode {access | trunk} Set the interface switchport mode as access or trunk; an interface in the
default mode (dynamic auto) cannot be configured as a secure port.
Step 4
switchport voice vlan vlan-id Enable voice VLAN on a port.
vlan-id—Spec
ify the VLAN to be used for voice traffic.
Step 5
switchport port-security Enable port security on the interface.
Step 6
switchport port-security
[maximum value [vlan {vlan-list |
{access | voice}}]]
(Optional) Set the maximum number of secure MAC addresses for the
interface. The maximum number of secure MAC addresses that you can
configure on a switch or switch stack is set by the maximum number of
available MAC addresses allowed in the system. This number is set by the
active Switch Database Management (SDM) template. See Chapter 8,
“Configuring the Switch SDM Template.” This number is the total of
available MAC addresses, including those used for other Layer 2 functions
a
nd any other secure MAC addresses configured on interfaces.
(Optional) vl
an—set a per-VLAN maximum value
Enter one of these options after you enter the vla
n keyword:
• vlan-list—On a trunk port, you can set a per-VLAN maximum value on
a range of VLANs separated by a hyphen or a series of VLANs separated
by commas. For nonspecified VLANs, the per-VLAN maximum value is
used.
• access—On an access port, specify the VLAN as an access VLAN.
• voice—On an access port, specify the VLAN as a voice VLAN.
Note The voice keyword is available only if a voice VLAN is configured on
a port and if that port is not the access VLAN. If an interface is
configured for voice VLAN, configure a maximum of two secure
MAC addresses.

Cisco Catalyst 3750-X Specifications

General

Switching Capacity	160 Gbps
Stacking Bandwidth	64 Gbps
Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
Form Factor	Rack-mountable
DRAM	256 MB
Flash Memory	64 MB
Model	Cisco Catalyst 3750-X Series
Ports	24 or 48 10/100/1000 Ethernet ports
Uplink Interfaces	4 SFP or 2 SFP+
Features	StackWise Plus, EnergyWise
Image	IP Base or IP Services
Operating Temperature	0 to 40°C
Operating Humidity	10 to 85% noncondensing
