Cisco Catalyst 3750-X User Manual

48-38
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-21521-01
Chapter 48 Configuring IP Multicast Routing
Configuring Optional IGMP Features
To return to the default setting, use the no ip pim spt-threshold {kbps | infinity} global configuration
command.
Modifying the PIM Router-Query Message Interval
PIM routers and multilayer switches send PIM router-query messages to find which device will be the
DR for each LAN segment (subnet). The DR is responsible for sending IGMP host-query messages to
all hosts on the directly connected LAN.
With PIM DM operation, the DR has meaning only if IGMPv1 is in use. IGMPv1 does not have an IGMP
querier elec
tion process, so the elected DR functions as the IGMP querier. With PIM-SM operation, the
DR is the device that is directly connected to the multicast source. It sends PIM register messages to
notify the RP that multicast traffic from a source needs to be forwarded down the shared tree. In this
case, the DR is the device with the highest IP address.
Beginning in privileged EXEC mode, follow these steps to
modify the router-query message interval.
This procedure is optional.
To return to the default setting, use the no i
p pim query-interval [seconds] interface configuration
command.
Configuring Optional IGMP Features
• Default IGMP Configuration, page 48-39
• Configuring the Switch as a Member of a Group, page 48-39 (optional)
• Controlling Access to IP Multicast Groups, page 48-40 (optional)
• Changing the IGMP Version, page 48-41 (optional)
• Modifying the IGMP Host-Query Message Interval, page 48-42 (optional)
Step 4
end Return to privileged EXEC mode.
Step 5
show running-config Verify your entries.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the interface to be configured, and enter interface configuration
mode.
Step 3
ip pim query-interval seconds Configure the frequency at which the switch sends PIM router-query
messages.
The default is 30 seconds. The range is 1 to 65535.
Step 4
end Return to privileged EXEC mode.
Step 5
show ip igmp interface [interface-id] Verify your entries.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.

Cisco Catalyst 3750-X Specifications

General

Switching Capacity	160 Gbps
Stacking Bandwidth	64 Gbps
Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
Form Factor	Rack-mountable
DRAM	256 MB
Flash Memory	64 MB
Model	Cisco Catalyst 3750-X Series
Ports	24 or 48 10/100/1000 Ethernet ports
Uplink Interfaces	4 SFP or 2 SFP+
Features	StackWise Plus, EnergyWise
Image	IP Base or IP Services
Operating Temperature	0 to 40°C
Operating Humidity	10 to 85% noncondensing
