Chapter 37 Configuring Network Security with ACLs
Configuring IPv4 ACLs
Creating a Numbered Standard ACL
Beginning in privileged EXEC mode, follow these steps to create a numbered standard ACL:
Use the no ac
cess-list access-list-number global configuration command to delete the entire ACL. You
cannot delete individual ACEs from numbered access lists.
Note When creating an ACL, remember that, by default, the end of the ACL contains an implicit deny
statement for all packets that it did not find a match for before reaching the end. With standard access
lists, if you omit the mask from an associated IP host address ACL specification, 0.0.0.0 is assumed to
be the mask.
This example shows how to create a standard ACL to deny access to IP host 171.69.198.102, permit
access to any others, and display the results.
Switch (config)# access-list 2 deny host 171.69.198.102
Switch (config)# access-list 2 pe
rmit any
Switch(config)# end
Switch# s
how access-lists
Standard IP access list 2
10 deny 171.69.198.102
20 permit any
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
access-list access-list-number {deny | permit}
source [source-wildcard] [log]
Define a standard IPv4 access list by using a source address and
wildcard.
The acces
s-list-number is a decimal number from 1 to 99 or 1300
to 1999.
Enter deny or
permit to specify whether to deny or permit access
if conditions are matched.
The sour
ce is the source address of the network or host from which
the packet is being sent specified as:
• The 32-bit quantity in dotted-decimal format.
• The keyword any as an abbreviation for source and
source-wildcard of 0.0.0.0 255.255.255.255. You do not need
to enter a source-wildcard.
• The keyword host as an abbreviation for source and
source-wildcard of source 0.0.0.0.
(Optional) The so
urce-wildcard applies wildcard bits to the
source.
(Optional) Enter lo
g to cause an informational logging message
about the packet that matches the entry to be sent to the console.
Step 3
end Return to privileged EXEC mode.
Step 4
show access-lists [number | name] Show the access list configuration.
Step 5
copy running-config startup-config (Optional) Save your entries in the configuration file.

Cisco Catalyst 3750-X Specifications

General

Switching Capacity	160 Gbps
Stacking Bandwidth	64 Gbps
Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
Form Factor	Rack-mountable
DRAM	256 MB
Flash Memory	64 MB
Model	Cisco Catalyst 3750-X Series
Ports	24 or 48 10/100/1000 Ethernet ports
Uplink Interfaces	4 SFP or 2 SFP+
Features	StackWise Plus, EnergyWise
Image	IP Base or IP Services
Operating Temperature	0 to 40°C
Operating Humidity	10 to 85% noncondensing
