Cisco Catalyst 3750-X User Manual

22-17
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-21521-01
Chapter 22 Configuring Optional Spanning-Tree Features
Configuring Optional Spanning-Tree Features
Note If you use BackboneFast, you must enable it on all switches in the network. BackboneFast is not
supported on Token Ring VLANs. This feature is supported for use with third-party switches.
You can configure the BackboneFast feature for rapid PVST+ or for the MSTP, but the feature remains
disabled (inactive) until you change the spanning-tree mode to PVST+.
Beginning in privileged EXEC mode, follow these steps to e
nable BackboneFast. This procedure is
optional.
To disable the BackboneFast feature, use the no spanni
ng-tree backbonefast global configuration
command.
Enabling EtherChannel Guard
You can enable EtherChannel guard to detect an EtherChannel misconfiguration if your switch is
running PVST+, rapid PVST+, or MSTP.
Beginning in privileged EXEC mode, follow these steps to
enable EtherChannel guard. This procedure
is optional.
To disable the EtherChannel guard feature, use the no spanning-
tree etherchannel guard misconfig
global configuration command.
You can use the sho
w interfaces status err-disabled privileged EXEC command to show which switch
ports are disabled because of an EtherChannel misconfiguration. On the remote device, you can enter
the show etherchannel summary privileged EXEC command to verify the EtherChannel configuration.
After the configuration is corrected, enter the shut
down and no shutdown interface configuration
commands on the port-channel interfaces that were misconfigured.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
spanning-tree backbonefast Enable BackboneFast.
Step 3
end Return to privileged EXEC mode.
Step 4
show spanning-tree summary Verify your entries.
Step 5
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
spanning-tree etherchannel guard
misconfig
Enable EtherChannel guard.
Step 3
end Return to privileged EXEC mode.
Step 4
show spanning-tree summary Verify your entries.
Step 5
copy running-config startup-config (Optional) Save your entries in the configuration file.

Cisco Catalyst 3750-X Specifications

General

Switching Capacity	160 Gbps
Stacking Bandwidth	64 Gbps
Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
Form Factor	Rack-mountable
DRAM	256 MB
Flash Memory	64 MB
Model	Cisco Catalyst 3750-X Series
Ports	24 or 48 10/100/1000 Ethernet ports
Uplink Interfaces	4 SFP or 2 SFP+
Features	StackWise Plus, EnergyWise
Image	IP Base or IP Services
Operating Temperature	0 to 40°C
Operating Humidity	10 to 85% noncondensing
