Chapter 26 Configuring IGMP Snooping and MVR
Configuring IGMP Filtering and Throttling
This example shows how to create IGMP profile 4 allowing access to the single IP multicast address and
how to verify the configuration. If the action was to deny (the default), it would not appear in the show
ip igmp profile output display.
Switch(config)# ip igmp profile 4
Switch(config-igmp-profile)# permi
t
Switch(config-igmp-profile)# range
229.9.9.0
Switch(config-igmp-profile)# end
Switch# s
how ip igmp profile 4
IGMP Profile 4
permit
range 229.9.9.0 229.9.9.0
Applying IGMP Profiles
To control access as defined in an IGMP profile, use the ip igmp filter interface configuration command
to apply the profile to the appropriate interfaces. You can apply IGMP profiles only to Layer 2 access
ports; you cannot apply IGMP profiles to routed ports or SVIs. You cannot apply profiles to ports that
belong to an EtherChannel port group. You can apply a profile to multiple interfaces, but each interface
can have only one profile applied to it.
Beginning in privileged EXEC mode, follow these steps to apply an IGMP profile to a switch port:
To remove a profile from an interface, use the no
ip igmp filter profile number interface configuration
command.
This example shows how to apply IGMP profile 4 to a port:
Switch(config)# interface gigabitethernet0/2
Switch(config-if)# ip igmp filter
4
Switch(config-if)# end
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the physical interface, and enter interface configuration mode.
The interface must be a Layer 2 port that does not belong to an
EtherChannel port group.
Step 3
ip igmp filter profile number Apply the specified IGMP profile to the interface. The range is 1 to
4294967295.
Step 4
end Return to privileged EXEC mode.
Step 5
show running-config interface
interface-id
Verify the configuration.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.

Cisco Catalyst 3750-X Specifications

General

Switching Capacity	160 Gbps
Stacking Bandwidth	64 Gbps
Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
Form Factor	Rack-mountable
DRAM	256 MB
Flash Memory	64 MB
Model	Cisco Catalyst 3750-X Series
Ports	24 or 48 10/100/1000 Ethernet ports
Uplink Interfaces	4 SFP or 2 SFP+
Features	StackWise Plus, EnergyWise
Image	IP Base or IP Services
Operating Temperature	0 to 40°C
Operating Humidity	10 to 85% noncondensing
