Cisco Catalyst 3750-X User Manual

31-4
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-21521-01
Chapter 31 Configuring UDLD
Configuring UDLD
Configuring UDLD
• Default UDLD Configuration, page 31-4
• Configuration Guidelines, page 31-4
• Enabling UDLD Globally, page 31-5
• Enabling UDLD on an Interface, page 31-6
• Resetting an Interface Disabled by UDLD, page 31-6
Default UDLD Configuration
Configuration Guidelines
• UDLD is not supported on ATM ports.
• A UDLD-capable port cannot detect a unidirectional link if it is connected to a UDLD-incapable
port of another switch.
• When configuring the mode (normal or aggressive), make sure that the same mode is configured on
both sides of the link.
Caution Loop guard works only on point-to-point links. We recommend that each end of the link has a directly
connected device that is running STP.
Ta ble 31-1 Default UDLD Configuration
Feature Default Setting
UDLD global enable state Globally disabled
UDLD per-port enable state for fiber-optic media Disabled on all Ethernet fiber-optic ports
UDLD per-port enable state for twisted-pair (copper) media Disabled on all Ethernet 10/100 and 1000BASE-TX ports
UDLD aggressive mode Disabled

Cisco Catalyst 3750-X Specifications

General

Switching Capacity	160 Gbps
Stacking Bandwidth	64 Gbps
Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
Form Factor	Rack-mountable
DRAM	256 MB
Flash Memory	64 MB
Model	Cisco Catalyst 3750-X Series
Ports	24 or 48 10/100/1000 Ethernet ports
Uplink Interfaces	4 SFP or 2 SFP+
Features	StackWise Plus, EnergyWise
Image	IP Base or IP Services
Operating Temperature	0 to 40°C
Operating Humidity	10 to 85% noncondensing
