1-33

Catalyst 3750-X and 3560-X Switch Software Configuration Guide

OL-21521-01

Chapter 1 Overview

Where to Go Next

Figure 1-12 Long-Distance, High-Bandwidth Transport Configuration

Where to Go Next

Before configuring the switch, review these sections for startup information:

• Chapter 2, “Using the Command-Line Interface”

• Chapter 3, “Assigning the Switch IP Address and Default Gateway”

95750

Access layer

Catalyst 4500

multilayer

switches

Eight

1-Gbps

connections

8 Gbps

Catalyst switches

CWDM

OADM

modules

CWDM

OADM

modules

Aggregation layer
