Cisco Catalyst 3750-X User Manual

B-26
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-21521-01
Appendix B Working with the Cisco IOS File System, Configuration Files, and Software Images
Working with Software Images
Image Location on the Switch
The Cisco IOS image is stored as a .bin file in a directory that shows the version number. A subdirectory
contains the files needed for web management. The image is stored on the system board flash memory
(flash:).
You can use the s
how version privileged EXEC command to see the software version that is currently
running on your switch. In the display, check the line that begins with
System image file is... . It
shows the directory name in flash memory where the image is stored.
You can also use the di
r filesystem: privileged EXEC command to see the directory names of other
software images that you might have stored in flash memory. You can use the archive download-sw
/directory privileged EXEC command to specify a directory once followed by a tar file or list of tar files
to be downloaded instead of specifying complete paths with each tar file. For example, in a mixed
hardware stack, you can enter archive download-sw /directory tftp://10.1.1.10/
c3750-ipservices-tar.122-35.SE.tar c3750e-universal-tar.122-35.SE2.tar.
File Format of Images on a Server or Cisco.com
Software images on a server or downloaded from Cisco.com are in a file format, which contains these
files:
• An info file, which serves as a table of contents for the file
• One or more subdirectories containing other images and files, such as Cisco IOS images and web
management files
This example shows some of the information contained in an info file. Ta
ble B-3 provides additional
details about this information:
system_type:0x00000000:c3750e-universal-mz.122-35.SE2
image_family:C3750E
stacking_number:1.9
info_end:
version_suffix:universal-mz.122-35.SE2
version_directory:c3750e-universal-mz.122-35.SE2
image_system_type_id:0x00000000
image_name:c3750e-universal-mz.122-35.SE2.bin
ios_image_file_size:6398464
total_image_file_size:8133632
image_feature:IP|LAYER_3|PLUS|MIN_DRAM_MEG=128
image_family:C3750E
stacking_number:1.9
board_ids:0x401100c4 0x00000000 0x00000001 0x00000003 0x00000002 0x00008000 0x00008002
0x4011000
0
info_end:
Note On Catalyst 3560-X switches, the stacking_number field does not apply to the switch.
Ta ble B-3 info File Description
Field Description
version_suffix Specifies the Cisco IOS imag
e version string suffix
version_directory Specifies the directory where the Cisco IOS imag
e and the HTML subdirectory are installed
image_name Specifies the name of the C
isco IOS image in the file

Cisco Catalyst 3750-X Specifications

General

Switching Capacity	160 Gbps
Stacking Bandwidth	64 Gbps
Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
Form Factor	Rack-mountable
DRAM	256 MB
Flash Memory	64 MB
Model	Cisco Catalyst 3750-X Series
Ports	24 or 48 10/100/1000 Ethernet ports
Uplink Interfaces	4 SFP or 2 SFP+
Features	StackWise Plus, EnergyWise
Image	IP Base or IP Services
Operating Temperature	0 to 40°C
Operating Humidity	10 to 85% noncondensing
