Cisco Catalyst 3750-X User Manual

12-17
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-21521-01
Chapter 12 Configuring Web-Based Authentication
Displaying Web-Based Authentication Status
This example shows how to configure a local banner with the custom message My Switch:
Switch(config) configure terminal
Switch(config)# aaa new-model
Switch(config)# aaa ip auth-proxy
auth-proxy-banner C My Switch C
Switch(config) end
For more information about the ip auth-proxy auth-proxy-banner command, see the “Authentication
Proxy Commands” section of the Cisco IOS Security Command Reference on
Cisco.com.
Removing Web-Based Authentication Cache Entries
This example shows how to remove the web-based authentication session for the client at the IP
address 209.165.201.1:
Switch# clear ip auth-proxy cache 209.165.201.1
Displaying Web-Based Authentication Status
Perform this task to display the web-based authentication settings for all interfaces or for specific ports:
This example shows how to view only the global web-based authentication status:
Switch# show authentication sessions
This example shows how to view the web-based authentication settings for gigabit interface 3/27:
Switch# show authentication sessions interface gigabitethernet 3/27
Step 3
end Return to privileged EXEC mode.
Step 4
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Command Purpose
clear ip auth-proxy cache {* | ho
st ip address} Delete authentication proxy entries. Use an asterisk to
delete all cache entries. Enter a specific IP address to
d
elete the entry for a single host.
clear ip admission cache {* | ho
st ip address} Delete authentication proxy entries. Use an asterisk to
delete all cache entries. Enter a specific IP address to
d
elete the entry for a single host.
Command Purpose
Step 1
show authentication sessions
[interface type slot/port]
Displays the web-based authentication settings.
type = fastethernet, gigabitethernet, or tengigabitethernet
(Optional) Use the interface k
eyword to display the
web-based authentication settings for a specific interface.
