11-53
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-21521-01
Chapter 11 Configuring IEEE 802.1x Port-Based Authentication
Configuring 802.1x Authentication
You can configure the maximum number of authentication attempts allowed before a user is assigned to
the restricted VLAN by using the dot1x auth-fail max-attempts interface configuration command. The
range of allowable authentication attempts is 1 to 3. The default is 3 attempts.
Beginning in privileged EXEC mode, follow these st
eps to configure the maximum number of allowed
authentication attempts. This procedure is optional.
To return to the default value, use the no dot1x aut
h-fail max-attempts interface configuration
command.
This example shows how to set 2 as
the number of authentication attempts allowed before the port moves
to the restricted VLAN:
Switch(config-if)# dot1x auth-fail max-attempts 2
Configuring the Inaccessible Authentication Bypass Feature
You can configure the inaccessible bypass feature, also referred to as critical authentication or the AAA
fail policy.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the port to be configured, and enter interface configuration mode.
For the supported port types, see the “802.1x Authentication
Configuration Guidelines” section on page 11-36.
Step 3
switchport mode access
or
switchport mode private-vlan host
Set the port to access mode,
or
Configure the Layer 2 port as a pri
vate-VLAN host port.
Step 4
authentication port-control auto
or
dot1x port-control auto
Enable 802.1x authentication on the port.
Step 5
dot1x auth-fail vlan vlan-id Specify an active VLAN as an 802.1x restricted VLAN. The range is 1 to
4094.
You can configure any active VLAN except an internal VLAN (routed
p
ort), an RSPAN VLAN, a primary private VLAN, or a voice VLAN as
an 802.1x restricted VLAN.
Step 6
dot1x auth-fail max-attempts max
attempts
Specify a number of authentication attempts to allow before a port moves
to the restricted VLAN. The range is 1 to 3, and the default is 3.
Step 7
end Return to privileged EXEC mode.
Step 8
show authentication interface-id
or
show dot1x interface int
erface-id
(Optional) Verify your entries.
Step 9
copy running-config startup-config (Optional) Save your entries in the configuration file.
