Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-21521-01
Chapter 42 Configuring IP Unicast Routing
Configuring Protocol-Independent Features
When an interface goes down, all static routes through that interface are removed from the IP routing
table. When the software can no longer find a valid next hop for the address specified as the forwarding
router's address in a static route, the static route is also removed from the IP routing table.
Specifying Default Routes and Networks
A router might not be able to learn the routes to all other networks. To provide complete routing
capability, you can use some routers as smart routers and give the remaining routers default routes to the
smart router. (Smart routers have routing table information for the entire internetwork.) These default
routes can be dynamically learned or can be configured in the individual routers. Most dynamic interior
routing protocols include a mechanism for causing a smart router to generate dynamic default
information that is then forwarded to other routers.
If a router has a directly connected interface to the specified default network, the dynamic routing
p
rotocols running on that device generate a default route. In RIP, it advertises the pseudonetwork 0.0.0.0.
A router that is generating the default for a network
also might need a default of its own. One way a
router can generate its own default is to specify a static route to the network 0.0.0.0 through the
appropriate device.
Beginning in privileged EXEC mode, follow these steps to define a static route to a network as the static
de
fault route:
Use the no ip d
efault-network network number global configuration command to remove the route.
When default information is passed through a dynamic routing protocol, no further configuration is
requ
ired. The system periodically scans its routing table to choose the optimal default network as its
default route. In IGRP networks, there might be several candidate networks for the system default. Cisco
routers use administrative distance and metric information to set the default route or the gateway of last
resort.
If dynamic default information is not being passed to the system, candidates for
the default route are
specified with the ip default-network global configuration command. If this network appears in the
routing table from any source, it is flagged as a possible choice for the default route. If the router has no
interface on the default network, but does have a path to it, the network is considered as a possible
candidate, and the gateway to the best default path becomes the gateway of last resort.
Using Route Maps to Redistribute Routing Information
The switch can run multiple routing protocols simultaneously, and it can redistribute information from
one routing protocol to another. Redistributing information from one routing protocol to another applies
to all supported IP-based routing protocols.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
ip default-network network number Specify a default network.
Step 3
end Return to privileged EXEC mode.
Step 4
show ip route Display the selected default route in the gateway of last resort
display.
Step 5
copy running-config startup-config (Optional) Save your entries in the configuration file.

Cisco Catalyst 3750-X Specifications

General

Switching Capacity	160 Gbps
Stacking Bandwidth	64 Gbps
Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
Form Factor	Rack-mountable
DRAM	256 MB
Flash Memory	64 MB
Model	Cisco Catalyst 3750-X Series
Ports	24 or 48 10/100/1000 Ethernet ports
Uplink Interfaces	4 SFP or 2 SFP+
Features	StackWise Plus, EnergyWise
Image	IP Base or IP Services
Operating Temperature	0 to 40°C
Operating Humidity	10 to 85% noncondensing
