48-25
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-21521-01
Chapter 48 Configuring IP Multicast Routing
Configuring IP Multicast Routing
Beginning in privileged EXEC mode, follow these steps to manually configure the address of the RP.
This procedure is optional.
To remove an RP address, use the no ip pi
m rp-address ip-address [access-list-number] [override]
global configuration command.
This example shows how to configure the address of the RP to 147.106.6.22 for multicast
g
roup 225.2.2.2 only:
Switch(config)# access-list 1 permit 225.2.2.2 0.0.0.0
Switch(config)# ip pim rp-address
147.106.6.22 1
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
ip pim rp-address ip-address
[access-list-number] [override]
Configure the address of a PIM RP.
By default, no PIM RP address is configured. You must configure the IP
ad
dress of RPs on all routers and multilayer switches (including the RP).
If there is no RP configured for a group, the switch treats the group as
dense, using the dense-mode PIM techniques.
A PIM device can be an RP for more than one group. Only one RP address
c
an be used at a time within a PIM domain. The access-list conditions
specify for which groups the device is an RP.
• For ip-address, enter the unicast address of the RP in dotted-decimal
notation.
• (Optional) For access-list-number, enter an IP standard access list
number from 1 to 99. If no access list is configured, the RP is used for
all groups.
• (Optional) The override keyword means that if there is a conflict
between the RP configured with this command and one learned by
Auto-RP or BSR, the RP configured with this command prevails.
Step 3
access-list access-list-number {deny |
permit} source [source-wildcard]
Create a standard access list, repeating the command as many times as
necessary.
• For access-list-number, enter the access list number specified in
Step 2.
• The deny keyword denies access if the conditions are matched. The
permit keyword permits access if the conditions are matched.
• For source, enter the multicast group address for which the RP should
be used.
• (Optional) For source-wildcard, enter the wildcard bits in dotted
decimal notation to be applied to the source. Place ones in the bit
positions that you want to ignore.
Recall that the access list is always terminated b
y an implicit deny
statement for everything.
Step 4
end Return to privileged EXEC mode.
Step 5
show running-config Verify your entries.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.
