Cisco Catalyst 3750-X User Manual

48-52
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-21521-01
Chapter 48 Configuring IP Multicast Routing
Configuring Basic DVMRP Interoperability Features
Beginning in privileged EXEC mode, follow these steps to configure a DVMRP tunnel. This procedure
is optional.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
access-list access-list-number {deny |
permit} source [source-wildcard]
Create a standard access list, repeating the command as many times as
necessary.
• For access-list-number, the range is 1 to 99.
• The deny keyword denies access if the conditions are matched. The
permit keyword permits access if the conditions are matched.
• For source, enter the number of the network or host from which the
packet is being sent.
• (Optional) For source-wildcard, enter the wildcard bits in dotted
decimal notation to be applied to the source. Place ones in the bit
positions that you want to ignore.
Recall that the access list is always t
erminated by an implicit deny
statement for everything.
Step 3
interface tunnel number Specify a tunnel interface, and enter interface configuration mode.
Step 4
tunnel source ip-address Specify the source address of the tunnel interface. Enter the IP address
of the interface on the switch.
Step 5
tunnel destination ip-address Specify the destination address of the tunnel interface. Enter the IP
address of the mrouted router.
Step 6
tunnel mode dvmrp Configure the encapsulation mode for the tunnel to DVMRP.
Step 7
ip address address mask
or
ip unnumbered type nu
mber
Assign an IP address to the interface.
or
Configure the interface as unnumbered.
Step 8
ip pim [dense-mode | sparse-mode] Configure the PIM mode on the interface.
Step 9
ip dvmrp accept-filter
access-list-number [distance]
neighbor-list access-list-number
Configure an acceptance filter for incoming DVMRP reports.
By default, all destination reports a
re accepted with a distance of 0.
Reports from all neighbors are accepted.
• For access-list-number, specify the access list number created in
Step 2. Any sources that match the access list are stored in the
DVMRP routing table with distance.
• (Optional) For distance, enter the administrative distance to the
destination. By default, the administrative distance for DVMRP
routes is 0 and take precedence over unicast routing table routes. If
you have two paths to a source, one through unicast routing (using
PIM as the multicast routing protocol) and another using DVMRP,
and if you want to use the PIM path, increase the administrative
distance for DVMRP routes. The range is 1 to 255.
• For neighbor-list access-list-number, enter the number of the
neighbor list created in Step 2. DVMRP reports are accepted only by
those neighbors on the list.
Step 10
end Return to privileged EXEC mode.

Cisco Catalyst 3750-X Specifications

General

Switching Capacity	160 Gbps
Stacking Bandwidth	64 Gbps
Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
Form Factor	Rack-mountable
DRAM	256 MB
Flash Memory	64 MB
Model	Cisco Catalyst 3750-X Series
Ports	24 or 48 10/100/1000 Ethernet ports
Uplink Interfaces	4 SFP or 2 SFP+
Features	StackWise Plus, EnergyWise
Image	IP Base or IP Services
Operating Temperature	0 to 40°C
Operating Humidity	10 to 85% noncondensing
