Configuring LED Patterns
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 229
9
STEP 3 Click Submit All Changes.
Local Progressing
LED
This phone attempts an outgoing call on this call
appearance (the called number is ringing).
Remote
Progressing LED
(applicable only to
shared call
appearance)
Another phone attempts an outbound call on this shared
call appearance.
Local Ringing LED The call appearance is ringing.
Remote Ringing
LED (applicable
only to shared call
appearance)
The shared call appearance is in ringing on another
phone.
Local Active LED The call appearance is engaged in an active call.
Remote Active LED
(applicable only to
shared call
appearance)
Another phone is engaged in an active call on this shared
call appearance.
Local Held LED The call appearance is held by this phone.
Remote Held LED
(applicable only to
shared call
appearance)
Another phone placed this call appearance on hold.
Register Failed LED The corresponding extension has failed to register with
the proxy server. Leaving this entry blank indicates the
default value.
Disabled LED Call Appearance is disabled (not available for any
incoming or outgoing call). Leaving this entry blank
indicates the default value.
Registering LED The corresponding extension tries to register with the
proxy server. Defaults to blank.
Call Back Active
LED
Call Back operation is currently active on this call.
Defaults to blank.
