Compaq ProLiant ML570

3-38 Compaq ProLiant ML570 Maintenance and Service Guide
Table 3-18
Array Diagnostic Utility (ADU) Error Messages
continued
Message Description Recommended Action
Drive (bay) X is a
replacement drive
marked OK
This drive has been replaced and
marked OK by the firmware. This
may occur if a drive has an
intermittent failure. For example, a
drive has previously failed, then
starts working again when ADU is
run.
Replace the drive.
Drive (bay) X is
failed.
The indicated physical drive has
failed.
Replace the drive.
Drive (bay) X is
undergoing drive
recovery
This drive is being rebuilt from the
corresponding mirror or parity data.
Normal operations should occur.
Drive (bay) X needs
replacing
The 210-MB hard drive has
firmware version 2.30 or 2.31.
Replace the drive.
Drive (bay) X upload
code not readable
An error occurred while ADU was
trying to read the upload code
information from this drive.
If there were multiple errors, the drive may need
to be replaced.
Drive (bay) X was
inadvertently
replaced
The physical drive was incorrectly
replaced after another drive failed.
1. Replace the drive that was incorrectly
replaced.
2. Replace the original drive that failed.
Do not run the server setup utility and try to
reconfigure.
Drive Monitoring
features are
unobtainable
ADU is unable to receive monitor
and performance data due to fatal
command problem (such as drive
time-out), or unable to receive data
due to these features not being
supported on the controller.
Check for other errors such as time-outs. If no
other errors occur, upgrade the firmware to a
version that supports the monitor and
performance.
Drive Monitoring is
NOT enabled for
SCSI Port X
Drive ID Y
The monitor and performance
features have not been enabled on
this drive.
Run the server setup utility to initialize the
monitor and performance features.
Drive time-out
occurred on physical
drive bay X
ADU issued a command to a
physical drive and the command
was never acknowledged.
The drive or cable may be bad. Check the other
error messages on the Diagnostics screen to
determine resolution.
Drive X indicates
position Y
Message indicates a designated
physical drive, which shows it to be
scrambled or in a drive bay other
than the one for which it was
originally configured.
Examine the graphical drive representation on
ADU to determine proper drive locations. Remove
drive X and place it in drive position Y. Rearrange
the drives according to the ADU instructions.
continued
