D-Link DGS-1250 Series User Manual

DGS-1250 Series Gigabit Ethernet Smart Managed Switch Web UI Reference Guide
5
Smart Wizard
After successfully connecting to the Web UI for the first time, the Smart Wizard embedded Web utility will be
launched. This wizard will guide the user through basic configuration steps that is essential for first time connection to
the Switch.
Step 1 - Web Mode
The Switch supports two Web Modes: Standard Mode and Surveillance Mode.
• The Standard Mode is used to configure, manage, and monitor most of the software features on the Switch.
• The Surveillance Mode is an additional web mode specifically designed to assist the user with surveillance
features supported by the Switch.
NOTE: The Web Mode can only be changed when one user session is connected to the Web UI of
the Switch.
Figure 2-3 Web Mode
The fields that can be configured are described below:
Parameter Description
Standard Mode
Select this option to access the Standard Mode after the Smart Wizard was
completed.
Surveillance Mode Select this option to access the Surveillance Mode after the Smart Wizard was
completed.
Tick the Ignore the wizard next time option to skip the Smart Wizard on the next login.

D-Link DGS-1250 Series Specifications

General

Model	DGS-1250 Series
Layer	Layer 2+
L3 Features	Static Routing
MAC Address Table	16K entries
Humidity	10% to 90% non-condensing
Type	Managed Switch
Ports	24 or 48 ports
Uplink Ports	4 x 10G SFP+
Switching Capacity	176 Gbps
Forwarding Rate	Up to 130.95 Mpps
Management	Web-based GUI, CLI, SNMP
Operating Temperature	0 to 50 °C
Storage Temperature	-40 to 70 °C
PoE Support	Available on some models (PoE/PoE+)
