FC 300 Design Guide
How to Program
Function:
Selectthetorquecharacteristicrequired.
VT and AEO are both energy saving operations.
Constant torque [0]: The motor shaft
output will provide constant torque under
variable speed control.
Variable Torque [1]: The motor shaft output will
providevariabletorqueunder variable speed control.
Set the variable torque level in par. 14-40 VT Level.
Automatic Energy Optimizing function [2]:
This function automatically optim ises energy
consumption by minim ising magnetisation
and frequency via par. 1 4-41 AEO Minimum
Magnetisation and par. 1 4-4 2 Minimum
AEO Frequency.
1-04 Overload Mode
Option:
*
High torque [0]
Normal torque [1]
Function:
High torque [0] allows up to 160% over torque.
Normal torque [1] is for oversized motors -
allows up to 110% over torque.
This parameter cannot be adjusted while
the motor is running.
1-05 Local Mode Configuration
Option:
Speed open-loop [0]
Speed closed-loop [1]
*
As conf. mode P. 1-00 [2]
Function:
Select wh ich application configuration mode (par.
1-00), i.e. application control principle, to use
when a Local (LCP) Reference is active. A Local
Reference can be active only when par. 3-13
Reference Site is set to [0] or [2]. By de fault the
local refe rence is active in Hand Mode only.
" 1-1* Motor selec tion
Parameter group for setting general motor data.
This parameter group cannot be adjusted
while the motor is running.
1-10 Motor Construction
Option:
*
Asynchronous [0]
PM, non-salient SPM (FC 302 only) [1]
Function:
Select the motor design type.
Select A synchronous [0] for asynchronous motors.
Select PM, non-salient SPM (FC 302 only) [1]
for permanent magnet (PM) motors.
Note that PM motors are divided into tw o groups,
with either surface m ounted (non-salient) or
interior (salie nt) magnets.
Motor design can be either asynchronous or
permanent magnet (PM) motor.
" 1-2* Motor Data
Parameter group 1-2* comprises input data from
the nameplate on the connected motor.
Parameters in pa rameter group 1-2* cannot be
adjusted while the m otor is running.
NOTE
Changing the value of these p arameters
affects the setting of other parameters.
1-20 Motor Power [kW]
Range:
0.5-10 HP [0.37-7.5 kW] [M-TYPE]
Function:
Enter the nominal motor power in kW a ccording
to the motor nameplate data. The default value
corresponds to the nominal rated outp ut of the unit.
This parameter cannot be adjusted while
the motor is running.
1-21 Motor Power [HP]
Range:
0.5-10 HP [M-TYPE]
Function:
Enter the nominal motor power in HP according
to the motor nameplate data. The default value
corresponds to the nominal rated outp ut of the unit.
This parameter cannot be adjusted while
the motor is running.
1-22 Motor V oltage
Range:
200-600 V [M-TYPE]
Function:
Enter the nominal motor voltage according to
the motor nameplate data. The default value
*
default setting ()display text []value for use in communication via serial communication port
160
MG.33.B
6.22 - V LT is a registered Danfoss trademark
