FC 300 Design Guide
How to Program
Function:
Set the motor current for release of the mechanical
brake, when a start condition is present. The upper
limit is specified in par. 16-37 Inv. Max. Current.
2-21 Activate Brake Sp ee d [RPM]
Range:
0-par. 4-53RPM
*
0RPM
Function:
Set the motor speed for activation of the
mechanical brake, when a stop condition is
present. The upper speed limit is specified in
par. 4-53 Warning Speed High.
2-22 Activa te Bra ke Sp eed [Hz]
Range:
0-Max. speed
*
0Hz
Function:
Set the motor freque ncy for activation of the
mechanical brake, when a stop condition is present.
2-23 Activa te Brake Delay
Range:
0.0 - 5.0 s
*
0.0s
Function:
Enter the brake delay tim e of the coast after
ramp-down time. The shaft is held at zero
speed with full holding torque. Ensure that the
mechanical brake has locked the load before
the motor enters coast mode. See Control
of Mechanical Brake section.
*
