FC 300 Design Guide
How to Program
" 1-** Load/Motor
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
1-0* General settings
1-00 Configuration mode [0] Speed open loop All set-ups FALSE - Uint8
1-01 Motor control principle [1] V VCplus All set-ups FALSE - Uint8
1-2* Motor data
1-20 Motor power [HP] Drive dependent All set-ups FALSE 1 Uint32
1-22 Motor voltage Drive dependent All set-ups FALSE 0 Uint16
1-23 Motor frequency Drive dependent All set-ups FALSE 0 Uint16
1-24 Motor current Drive dependent All set-ups FALSE -2 Uint16
1-25 Motor nominal speed Drive dependent All set-ups FALSE 67 Uint16
1-29 Automatic motor adaptation(AMA) [0] Off All set-ups FALSE - Uint8
1-3* Advanced motor data
1-30 Stator resistance (Rs) Motor dependent All set-ups FALSE -4 Uint32
1-31 Rotor resistance (Rr) Motor dependent All set-ups FALSE -4 Uint32
1-33 Stator leakage reactance (X1) Motor dependent All set-ups FALSE -4 Uint32
1-34 Rotor leakage reactance (X2) Motor dependent All set-ups FALSE -4 Uint32
1-35 Main reactance (Xh) Motor dependent All set-ups FALSE -4 Uint32
1-36 Iron loss resistance (Rfe) Motor dependent All set-ups FALSE -3 Uint32
1-39 Motor poles Motor d ependent All set-ups FALSE 0 Uint8
1-5* Load indep. setting
1-50 Motor magnetiz ing at zero speed 100 % All set-ups TRUE 0 U int16
1-51 Min speed normal m agnetizing [RPM] 1 RPM All set-ups TRUE 67 Uint8
1-6* Load depen. setting
1-60 Low speed load compensation 100 % All set-ups TRUE 0 Int16
1-61 High spee d load compensation 100 % All set-ups TRUE 0 Int16
1-62 Slip compensation 100 % All set-ups TRUE 0 Int16
1-63 Slip compensation time constant 0.10 s A ll set-ups TRUE -2 Uint16
1-64 Resonance dampening 100 % All set-ups TRUE 0 Uint16
1-65 Resonance dampening time constant 5 ms All set-ups TRUE -3 Uint8
1-66 Min. current at low speed 100 % A ll set-ups TRUE 0 Uint8
1-67 Load type [0] Passive load All set-ups TRUE - Uint8
1-68 Minimum inertia Drive dependent All set-ups FALSE -4 Uint32
1-69 Maximum inertia Drive dependent All set-ups FALSE -4 Uint32
1-7* Start adjustments
1-71 Start delay 0.0 s All se t-ups TRUE -1 Uint8
1-72 Start function [2] Coast/delay time All set-ups TRUE - Uint8
1-74 Start speed [RPM] 0 RPM All set-ups TRUE 67 Uint16
1-76 Start current 0.00 A All set-ups TRUE -2 Uint16
1-8* Stop adjustments
1-80 Function at stop [0] Coast All set-ups TRUE - U int8
1-81 Min speed for function at stop [RPM] 0 RPM A ll set-ups TRUE 6 7 Uint16
1-9* Motor temperature
1-90 Motor thermal protection [0] No protection All set-ups TRUE - Uint8
1-91 Motor external fan [0] No All set-ups TRUE - Uint16
1-93 Thermistor source [0] None All set-ups FALSE - Uint8
*
default setting ()display text []value for use in communication via serial communication port
256
MG.33.B
6.22 - V LT is a registered Danfoss trademark
