Danfoss FC 300 Design Guide

FC 300 Design Guide
Introduction to FC 300
Immunity continued
FC 301/FC 302; 200-240 V, 380-500 V
Basic standard Burst
IEC 61000-4-4
Surge
IEC 61000-4-5
ESD
IEC
61000-4-2
Radiated elect ro magnetic field
IEC 61000-4-3
RF common
mode voltage
IEC 61000-4-6
Acceptance criterion B B B A A
Line
4kVCM
2kV/2Ω DM
4kV/12Ω CM
— — 10 V
RMS
Motor 4kVCM 4kV/2Ω
1)
— — 10 V
RMS
Brake 4kVCM 4kV/2Ω
1)
— — 10 V
RMS
Load sharing 4kVCM 4kV/2Ω
1)
— — 10 V
RMS
Control wires 2kVCM 2kV/2Ω
1)
— — 10 V
RMS
Standard bus 2kVCM 2kV/2Ω
1)
— — 10 V
RMS
Relay w ires 2kVCM 2kV/2Ω
1)
— — 10 V
RMS
Application and serial
communication options
2kVCM
2kV/2Ω
1)
— — 10 V
RMS
LCP cable 2kVCM 2kV/2Ω
1)
— — 10 V
RMS
External 2 4 V D C
2kVCM
0.5 kV/2 Ω DM
1kV/12Ω CM
— — 10 V
RMS
Enclosure
— —
8kVAD
6kVCD
10 V/m —
AD: Air Discharge
CD: Contact Discharge
CM: Common mode
DM: Differential mode
1. Injection on cable shield.
44
MG.33.B6.22 - VLT is a registered Danfoss trademark
