FC 300 Selection
Set-up exampl e
In this example, a permanent magnet (PM) motor is used with resolver as speed feedback.
A PM motor must usually operate in flux mode.
Wiring:
The max cable l ength is 490 ft [150 m] when a twisted -pair cable is used.
NOTE
The resolver cable shielding m ust be correctly connected to the de-coupling plate and
connected to the chassis (ground) on the motor side.
NOTE
Always use shielded motor cables and brake chopper cables.
Adjust the following parameters:
Par. 1-00 Configuration Mode Speed closed-loop [1]
Par. 1-01 Motor Control Principle Flux with feedback [3]
Par. 1-10 Motor Construction PM, non-salient SPM [1]
Par. 1-24 Motor Current Nameplate
Par. 1-25 Motor Nominal Speed Nameplate
Par. 1-26 Motor Cont. Rated Torque Nameplate
AMA is not pos sible on PM motors
Par. 1-30 Stator Resistance Motor data sheet
Par. 1-37 d-axi s inductance (Ld) Motor data sheet (mH)
Par. 1-39 Motor Poles Motor data sheet
Par. 1-40 Back EMF at 1000 RPM Motor data sheet
Par. 1-41 Motor Angle Offset Motor data sheet (Usually zero)
Par. 17-50 Poles Resolver data sheet
Par. 17-51 Input Voltage Resolver data sheet
Par. 17-52 Input Frequency Resolver data sheet
Par. 17-53 Transformation Ratio Resolver da ta sheet
Par. 17-60 Feedback Direction
Par. 17-61 Feedback Signal Monitoring Hardware check of resolver connections
78
MG.33.B6.22 - VLT is a registered Danfoss trademark
