Danfoss iC7 Series Design Guide

10.2.16 Dimensions of the DC Filter for DM10L
A
B
C
Ø18
(Ø0.71)
150
(5.91)
279
(10.98)
424
(16.69)
429
(16.89)
18
(0.71)
18
(0.71)
656
(25.83)
623
(24.53)
2
(0.08)
50
(1.97)
45
(1.77)
140
(5.51)
20
(0.79)
29
(1.14)
29
(1.14)
41
(1.61)
41
(1.61)
20
(0.79)
15
(0.59)
15
(0.59)
15
(0.59)
10
(0.39)
10
(0.39)
64.5
(2.54)
10
(0.39)
502
(19.76)
402
(15.83)
302
(11.89)
337
(13.27)
184
(7.24)
149
(5.87)
42
(1.65)
6xM8
13
(0.51)
17
(0.67)
M6 max.
15 (0.59)
3xØ4.5
(3xØ0.18)
3xØ4.5
(3xØ0.18)
3xM6
14 (0.55)
3xM6
14 (0.55)
323.5
(12.74)
2x40=80
(2x1.58=3.15)
2x40=80
(2x1.58=3.15)
e30bk443.10
A Center of gravity B View from the bottom
C View from the top
Figure 142: Dimensions of the DC Filter for DM10L in mm (in)
142 | Danfoss Drives Oy © 2024.03 AJ475942178716en-000101 / 172K2848A
Design Guide | iC7 Series Liquid-cooled System Modules
